UPEK EikonTouch 700 is a FIPS 201 certified capacitive USB 2.0 fingerprint scanner.
Even though this is the mac version, the only difference is the packaging - where the software can be downloaded from Authentec's website. The pc software works great as well. All was great until the first one i ordered suddenly stopped working. The fingerprint reader seemed to think that a finger was swiping it in a loop. It would no longer work. With this UPEK Eikon TrueMe USB Fingerprint Reader for PC and Mac, you can be sure to secure your system completely, with your fingerprint being the only way to access it! The Eikon TrueMe features a USB interface, and digitally scans your fingerprint to give you access to your system. Keep your investment secure, and use the Eikon TrueMe as. With this UPEK Eikon TrueMe USB Fingerprint Reader for PC and Mac, you can be sure to secure your system completely, with your fingerprint being the only way to access it! The Eikon TrueMe features a USB interface, and digitally scans your fingerprint to give you access to your system.
The scanner is no longer manufactured. Its successor is EikonTouch 710 by DigitalPersona.
Support modules for this scanner are included in MegaMatcher 12.1 SDK, MegaMatcher On Card 11.2 SDK, VeriFinger 12.1 SDK and Free Fingerprint Verification SDK.
Specifications
| Scanner Name | EikonTouch 700 |
| Manufacturer | DigitalPersona, Inc. Previously by UPEK, Inc. |
| Connection | USB 2.0 |
| Supported OS (*) | Microsoft Windows (32-bit and 64-bit), Android (with root access) |
| Resolution | 508 ppi |
| Image capture area (Platen size) | 13 x 18 mm (0.5' x 0.7') |
| Fingerprint image size | 256 x 360 pixels |
| Sensor type | Capacitive |
| Device size | 84 x 34 x 14 mm (3.3' x 1.4' x 0.6') |
| Device weight | 74 grams (2.9 oz) |
| Operating temperature | 0°C ~ +40°C |
| Operating humidity | 5% - 93% at +30°C |
* These operating systems are supported by Neurotechnology SDKs. Device manufacturers may have different lists of supported operating systems.
Neurotechnology Solution Partners use this scanner in
The EikonTouch 700 fingerprint readers are used in these systems, created by Neurotechnology Solution Partners:
- Anaxee-Neurotech Attendance – an access and attendance control system developed by Anaxee Technologies Pvt. Ltd.
Other UPEK scanners
Neurotechnology SDKs include support module for these UPEK scanners:
- EikonTouch 300 – a flat fingerprint reader with capacitive TCS2S touch sensor and rugged coating.
- EikonTouch 500 – a flat fingerprint reader with capacitive TCS1S touch sensor and rugged coating.
- Eikon – a desktop fingerprint reader, based on TCS4C capacitive swipe sensor.
- Eikon Solo – a desktop fingerprint reader, based on TCS5B capacitive swipe sensor.
- Eikon To Go – a fingerprint reader in dongle form factor, based on TCS4C capacitive swipe sensor.
Click to zoom
Sensor close-up
Click to zoom
UPEK Eikon Solo is a swipe fingerprint reader with USB 2.0 connection. The fingerprint reader is based on TCS5B capacitive fingerprint sensor.
The scanner is no longer manufactured.
Support modules for this scanner are included in MegaMatcher 12.1 SDK, MegaMatcher On Card 11.2 SDK and VeriFinger 12.1 SDK.
Specifications
| Scanner Name | UPEK Eikon Solo |
| Manufacturer | DigitalPersona, Inc. Previously by UPEK, Inc. |
| Connection | USB 2.0 |
| Supported OS (*) | Microsoft Windows (32-bit and 64-bit), Linux (32-bit and 64-bit), macOS (x86 32-bit and 64-bit), Android (with root access) |
| Resolution | 508 ppi |
| Image capture area (Platen size) | 25 x 7 mm (1.0' x 0.3') |
| Fingerprint image width | 144 pixels |
| Sensor type | Capacitive, CMOS |
| Device size | 84 x 34 x 14 mm (3.3' x 1.4' x 0.6') |
| Device weight | 68 g (2.4 oz) |
| Operating temperature | 0°C ~ +40°C |
| Operating humidity | 5% - 93% at +30°C |
* These operating systems are supported by Neurotechnology SDKs. Device manufacturers may have different lists of supported operating systems.
Other UPEK scanners
Neurotechnology SDKs include support module for these UPEK scanners:
Eikon Mini Usb Fingerprint Reader For Pc
- EikonTouch 300 – a flat fingerprint reader with capacitive TCS2S touch sensor and rugged coating.
- EikonTouch 500 – a flat fingerprint reader with capacitive TCS1S touch sensor and rugged coating.
- EikonTouch 700 – a FIPS 201 / PIV compliant flat fingerprint reader with capacitive TCS1C touch sensor.
- Eikon – a desktop fingerprint reader, based on TCS4C capacitive swipe sensor.
- Eikon To Go – a fingerprint reader in dongle form factor, based on TCS4C capacitive swipe sensor.
